Quad Axle

All-American 28-Ft Quad

FL2827-4

Perfect for hauling aggregate on federal highways in all 50 states. This frameless quad axle trailer is a featherweight model. The patented design provides the highest yield strength in the industry. Its feature package provides the necessities most haulers need and is ready to maximize your payload.

  • Tare Weight9,441 lb
  • Capacity27 Yards
  • Body TypeFL2827-4

CLICK THE DROP DOWN ARROWS TO VIEW FEATURES.

Technical Specs

Key Features

Bolted Body with Superior Strength
Manual Lift Axle
Switch and Valve Cartridge
Ridewell RAR266 Suspension
Ridewell 239 Quad Axle
Aluminum Wheels
Aluminum Stiff Legs
LED Lights
Controls Run to the Cab
Kingpin Rollers
Trapezoidal Member Subframe

Optional Features

UHMW Extra Wide Liner
UHMW Floor Liner
Automatic Lift Axle
Disc Brakes
Tire Inflation System
2-Speed Landing Gear
Grain Gate w/Screw Locks
Screw Locks
Full Flaps
Aluminum 22.5”
Aluminum 24.5”
Aluminum Super Single
Alcoa Dura-Bright 22.5”
Alcoa Dura-Bright 24.5”
Alcoa Dura-Bright Super Single
Galvanized Hangars
Aero Force Flip Tarp
Roll Rite Single Cable Slide Tarp
Roll Rite Electric Side Roll Tarp
Mountaintarp Manual Side Roll - Vinyl
Mountaintarp Tarp N Go - Mesh
Mountaintarp Tarp N Go - Vinyl
4- Way Electric Over Air Tailgate Control
6-Way Electric Over Air Tailgate Control
4-Way Electric Over Air Lift Axle Control
6- Way Electric Over Air Lift Axle Control
Ridewell 245R
Air-Lift Tailgate
Clearance Lights Rear Post
Extra Marker Lights Bottom of Sides
Extra Marker Lights Top of Sides
Air-Weigh LoadMaxx Plus
Air-Weigh Quickload Plus
Splash Guards
Inside Steps
Wood Boards - 6"
Push Blocks
Air Cab Kit
Document Holder
Spreader Chain on Tailgate

Dimensions

Body Type
FL2827-4
Capacity
27 Yards
Inside Width
93"
Inside Length
26'
Side Height
44"
Nose Height
44"
Tailgate Height
44"
TG Slope
15 Degrees
Kingpin to Rear Axle
298"
Kingpin Setting
-7.5"
Draft Arms
140"
Kingpin to Stiff Legs
108"
Suspension
Ridewell RAR266
Axle
77.5” Track, 5.75 Dia, .394”Wall
Wheel Size
8.25x24.5
Tire Size
11R24.5
Hoist Size
8” Trunnion Mount
Tare Weight
9,441 lb
